R1500

Cement Additive

Introduction

R1500 is a single part modified styrene butadiene liquid additive for cement mortars which enhances physical and chemical properties, allows mortars to be placed in thin section, provides waterproofing and resistance to frost and promotes adhesion to building surface. Mortars containing R1500 are used for a wide range of applications where high strength and good performance mortars are required.

R1500 is supplied as single component in white liquid. According to its specified use within mortars it is diluted with water and added to cement, sand (and aggregate) mixture to provide the required performance characteristics. As a priming or bonding coat, it is mixed with cement only to provide adhesion between substrate and mortar.

Application

bulletFloor screeds
bulletConcrete repair
bulletWaterproof renders
bulletSlurry coats
bulletHeavy duty floor toppings
bulletProtection of steel reinforcement
bulletBedding and bonding mortars
bulletTanking and waterproofing

Mixing

Mortars containing R1500 is used exactly as conventional mortar mixes. R1500 does not act as an accelerator or retarder. In warm conditions R1500 modified mortars my achieve a false set on the surface as a result of the polymer film drying. Reworking the mortars without the use of extra liquid will overcome this. It can be used in most weather conditions and in a wide temperature range, from +30C to 250C. At high ambient temperature the working time will reduce.

Advantages

bullet

Mortars can be applied in thin section

bullet

High compressive, tensile and flexural strengths

bullet

Monolithic adhesion to building substrates

bullet

Cured mortars are waterproof

bullet

Resistant to freeze/thaw cycling

bullet

Mortar, toppings and renders are more resistant to mild chemical

bullet

attach.

bullet

No harm to human shin

Storage

R1500 should be stored in dry warehouse conditions away from direct heat and sunlight. Shelf life is approximately 12 months in unopened containers.

Packing

In 5kg

　

General Application of R1500 Cement Additive            (For reference only and depending actual site condition)

Cement Slurry(Cement/R1500)

Suitable for window sill, skirting, wall and slightly water seepage areas. The substrate should be firm and sound for adherence of the cement slurry. After application by brush or trowel, reinstatement of finishing is as usual.

Cement Mortar(Cement/Sand/R1500)

Suitable for the floor of bathroom, balcony, drainage hole, water tank, basement and V-cutting on cracks as general application of waterproofing rendering.

Specification

3:1 aggregate/R1500cement 3:1 aggregate/R1500cement
Compressive strenght 70N/mm2 Acid/alkali resistance

resist certain mild chemicals such as 5% lactic, dil, hydrochloric, some salts. Detergents, antiseptics, cleaning fluid dung, urine, some animal fats.
Tensil strenght 6.7N/mm2
Flexural strenght 15.2N/mm2
Workability excellent Minimum cure temperature above 30C
Freezz/thaw resistance excellent Bonding timber fair
Water vapour permeability 4% Adhesion to steel good
Surface water permeability liquid water very low Maximum thickness per coat 62mm
Coefficient of thermal expansion 12.8x10-6 0C Shrinkage during cure 0.01%
Substrate condition before application clean and damp Tolerance to da,p and wet conditions excellent

Mixing Ratio

R1500 mortar mixing ratio 　

cement

medium sharp sand

granite    chips (6-3mm)

pea shingle(10-5mm)

R1500 (litre) approx.

water (litre)approx.

yield (M3) approx.

coverage

approx.
Floor screeds    6-25mm weight

50kg

125kg

 　 　

9

9

0.1

10m2@10mm
volume

1

2

 　 　

1:1 water

 　 　 　
Floor toppings 12-25mm weight

50kg

75kg

75kg

 　

9

9

0.1

10m2@10mm
volume

1

1.25

1.25

 　

1:1 water

 　 　 　
Concrete repair with steel bar weight

50kg

125kg

 　 　

14

4

0.1

10m2@10mm
volume

1

2

 　 　

3:1 water

 　 　 　
Light weight concrete 38mm+ weight

50kg

150kg

 　 　

4.5

13.5

0.1

10m2@10mm
volume

1

2.5

 　 　

1:3 water

 　 　 　
Fine concrete 50mm+ weight

50kg

100kg

 　

100kg

4.5

 　

0.14

5.6m2@25mm
volume

1

1.5

 　

1.5

1:3 water

 　 　 　
Slurry coat         1-3mm weight

50kg

50kg

 　 　

35

 　

0.1

 　
volume

1

1

 　 　 　 　 　

105-122m2
